How to Charge Battery by Solar Panels?

If you are connecting a solar panel directly to a battery, you should definitely use a solar charge controller unless the panel is very small. In general, a 5-watt solar panel can be connected directly to the battery terminal; however, a solar regulator is needed for larger solar panels in order to keep the battery from overcharging.

It is important to understand that using solar power to refill used energy is not always possible before we start. In ideal summer illumination circumstances, think about recharging a 100-amp-hour battery with a 30-watt solar panel. From this example, you can see that a 100-amp-hour battery will take many days to fully recharge, requiring at least 100 watts of solar energy.

Powering Remote Areas: LiFePO4 Batteries in Off-Grid Solutions

How Can Solar Panels Be Used to Charge a Battery?

Batteries can occasionally be charged directly by solar panels, though this is not always the case. Batteries can be charged using solar panels. In order to safeguard the battery, a charge controller is usually needed to adjust the solar panel’s voltage output to a level suitable for the battery that is being charged. If you use a solar panel to directly charge a battery, you should use a charge controller to control the flow of electricity.

Method 1: Solar Panel Charging DIY Battery

Charging your batteries with a solar panel is an excellent way to provide clean, sustainable energy.

Step 1: Install Charge Controller

Install the charge controller on a stable platform and away from the elements. Rather, place the charge controller in a far-off place and connect the panel to the controller via cables.

Step 2: Attach the Battery

Two wires must be attached to your battery, one for positive and one for negative. If you are able to tell the positive from the negative cable, it is advised to proceed with caution.

In an alternative configuration, the positive would be a solid red wire, and the negative would be a black wire bearing writing.

Naturally, if the cables in your battery bank are already linked, you won’t need to add any more to the battery initially.

Step 3: Charge input ports of controller

For the most part, the wire ends that plug into the charge controller don’t require any connectors attached.

To prevent your controller or battery from being shorted out, make sure the positive and negative cables are connected to the appropriate ports.

If a 12V battery is being attached, use wire that is either 10- or 16-gauge.

Step 4: Charge controller connected to wires

A common application for MC4 connections, which are long, cylindrical fittings having a male and a female side, is joining the output wires of solar panels. Using a screwdriver, tighten the screws holding the input wires in place by slipping their bare ends into the charging connection’s input ports, just like you did with the output wire connections.

Step 5: Connect the solar panel and controller.

There should be two free lines with MC4 connections at either end once the input wires are connected to the charging connector. Gently insert the male and female MC4 connectors into their respective holes on the solar panel, then snap them into place.

One should always exercise caution when handling electricity. Verify again that the positive and negative connections are connected appropriately.

Step 6: Charge controller output

Verify that the output of the charge connector is working. You can check the amount of current travelling to the battery on the majority of charge connectors thanks to their digital displays. If the readings are zero, make sure everything is connected correctly by checking again. You can use your tablet or smartphone to check the voltage because certain charging ports have the ability to communicate with an app.

Step7: Use the solar panel to charge the battery

Keep the battery attached to the connector until it is fully charged. It will be useful to have your digital display in this case. When the output starts to decline, the battery is virtually fully charged.

Method 2: Using an MPPT Charge Controller

When used properly, solar panels can be an excellent way to recharge your batteries. The usage of charge controllers in conjunction with solar panels is essential for battery charging since they regulate the power coming from the panels.

Step 1: Verify the Wattage of the Solar Panel

The rear of the panel should display the wattage. An indicator of the watts your solar panel can produce should usually be on the back of the panel.

When solar panels are rated for a voltage, their power output is meant to be higher. For example, a solar panel designed to generate 12V may generate 17V. This is because under ideal conditions, they will only produce their maximum voltage.

If more energy is produced by the solar panel than the battery can hold, the battery could be damaged and overcharged. One tool that can help prevent this is a charge controller.

Step 2: Rating of Solar Watts

While the majority of solar chargers are limited to 12 VDC, we do offer a limited range of 24-volt panels. When requiring 24 volts or more, solar panel is usually wired in series. We are able to place an order for solar panels that are specifically made to produce greater DC voltages—24, 36, 48, and so on.

Deduct the battery voltage from the solar panel power. Divide this amount by the wattage that was specified on the back of the solar panel. Because charge controllers are often rated in multiples of 30 amps, you can round up to the next highest rating if the capacity is more than 30 amps. For example, to get 25 amps from a 300W solar panel to charge a 12V battery, you would divide 300 by 12. After that, you would buy a charging controller rated for 30 amps.

Step 3: Select a Charge Controller with MPPT

A charge controller using MPPT technology will work better. The solar panel can provide to the battery the maximum voltage will be controlled by both. The energy storage and transmission capacity of MPPT charge controllers is 30% more than that of PWM ones. Furthermore, MPPT charge controllers can be utilized with solar panel strings, whereas PWM charge controllers cannot. Greater energy efficiency of these options can quickly offset their higher cost as compared to PWM devices.

The Charge Controller: What Is It?

The current flowing into the battery from the solar panel is managed by a charge controller. It serves as a switch for on and off. It also ensures the battery is charged to the appropriate voltage.

A 12-volt solar panel usually generates more than that, more electricity than the battery needs. The charge controller regulates the voltage provided to the battery, allowing just the necessary current to pass through it.

During the battery is charged fully, the charge controller will also cut the energy. The battery is protected from overcharging, which can shorten its life and damage. Only then will the controller start allowing the current to flow again once the battery starts to run low.

The Various Solar Panel Battery Types

Of the three types of primary secondary batteries, the lead-acid type is the most commonly used. Batteries based on nickel are far less common. Lithium-ion battery is applied in a lot of consumer electronics, including as phones and computers, and they are becoming more and more common secondary batteries.

Lithium Batteries

As the world grows increasingly reliant on electronic devices, there is a greater need than ever for sustainable energy sources. it has significant drawbacks.

Its primary disadvantage is that solar panels require batteries to store their energy. Lithium-ion battery is the most often applied battery type in solar panel systems. Charging one, though, can be difficult. While using solar panel to charge lithium battery is actually rather simple.

Lead-acid Battery

The type of battery most commonly used in solar cells is the lead-acid battery. They are as well as the original kind of rechargeable battery. In 1859, French physicist Gaston Planté invented the first lead-acid battery. Lead-acid battery works by reactivity of the metal lead with sulfuric acid to create an electric current. Solar energy systems can be able to charge lead-acid battery.

Your lead-acid batteries can be kept fully charged without the use of grid electricity using solar charging. Lead-acid battery is incredibly durable and trustworthy. But they need a little maintenance. To make sure lead-acid battery is free of corrosion and clean, they need to be tested regularly.

Deep Cycle Lead Acid Batteries

A certain type of battery known as a deep cycle battery is capable of numerous discharges and recharges without experiencing any damage. Being able to store solar energy during the day and produce power at night or on cloudy days makes them a common component of solar energy systems.

If you want to make sure that a deep-cycle battery is charged properly, there are a few things to keep in mind when charging it with a solar panel. The solar panel needs additional electricity to replenish the battery, so make sure it is receiving adequate sunlight.

Furthermore, link the negative and positive leads of the solar panel to the terminals of the battery. Lastly, check the charging process to insure the voltage and capacity levels are within allowable bounds.

Last Words

Using solar power to charge a battery is a great method to go green and live a more sustainable lifestyle if you’re thinking of cutting off from the grid. Solar energy is practical and clean, whether it is used to power small equipment during a van trip, your cell phone, or a standalone battery for camping. The solar battery, solar panel, charge controller, and method for charging a battery using the solar panel are all covered in this article.
